Comprehensive Product Introduction: Dongfeng Duolika Faecal Suction Truck (Model CL5140GXW6ACC) | DFAC 4×2 Faecal Suction Truck with 10 Cubic Meter Tank Capacity

I. Product Overview

The Dongfeng Duolika Faecal Suction Truck (Model CL5140GXW6ACC) is a heavy-duty, multi-functional sanitation vehicle designed for efficient sewage collection, transportation, and high-pressure cleaning operations. As a specialized combination sewer cleaning truck, it integrates both vacuum suction for sludge and liquid waste and high-pressure water jetting for pipe cleaning. This unit is engineered to meet the demanding requirements of municipal drainage maintenance, industrial waste management, and residential septic tank cleaning. By combining powerful suction capabilities with robust carrying capacity, this truck ensures rapid waste removal and effective pipeline unblocking, making it an indispensable asset for urban sanitation departments and environmental protection agencies.

II. Core Parameters

The following table outlines the critical specifications of the Dongfeng Duolika Faecal Suction Truck, highlighting its powerful performance and operational efficiency.

III. Dimensions, Materials & Design Philosophy

The design of the Dongfeng Duolika faecal suction truck focuses on maximizing durability, operational safety, and waste handling efficiency. The vehicle dimensions are engineered around a 3800mm wheelbase, providing optimal weight distribution and stability when fully loaded with liquid waste. The suction tank features a capacity of approximately 10 cubic meters, constructed from high-strength carbon steel with a wall thickness of 6mm for the sludge tank. This robust construction ensures resistance to corrosion and impact during heavy-duty use. The design philosophy prioritizes "efficient suction and safe transport." The tank is equipped with an anti-overflow valve positioned at the lowest possible point at the top to prevent liquid from entering the vacuum system. The water circulation pump tank is also constructed from carbon steel for durability, while strategically placed dual side toolboxes provide convenient storage for operational accessories.

IV. Detailed Structure: Engine, Transmission, Axles, and Chassis

This model boasts a robust configuration ensuring powerful suction and smooth operation.

• Main Engine & Power System: The chassis is powered by a Yuchai 165 horsepower diesel engine, compliant with Euro VI emission standards. This provides ample power for the vehicle's road travel and drives the power take-off (PTO) system for vacuum pump operation.

• Transmission & Drive System: It features a heavy-duty manual transmission matched to the Yuchai engine. The PTO system transfers engine power to the SK-12 water circulation vacuum pump, ensuring reliable suction performance.

• Axles & Chassis: The vehicle utilizes a heavy-duty axle configuration suitable for a 14-ton gross vehicle weight rating, supported by a reinforced frame. This provides the necessary load-bearing capacity for the 10-ton liquid load and ensures stability during transport and vacuum operations.

• Tire & Braking System: Fitted with 825R20 steel wire radial tires, the truck offers excellent grip, load distribution, and durability for both highway and rough terrain operation.

V. Product Features & Manufacturer Advantages (Chengli Group)

The Dongfeng Duolika Faecal Suction Truck is packed with advanced features, backed by the manufacturing excellence of Chengli Group.

Product Features:

• High-Efficiency Vacuum System: Equipped with an SK-12 water circulation vacuum pump, this system generates powerful suction for rapid loading of sludge and liquid waste. The vacuum pressure gauge is conveniently mounted near the water tank for easy monitoring by the operator.

• Optimized Tank Design: The 10 cubic meter suction tank is fabricated from 6mm thick carbon steel for extended service life. The anti-overflow valve is strategically positioned at the lowest possible point at the tank top to maximize fill capacity while preventing liquid carryover into the pump.

• Efficient Discharge System: Waste discharge is facilitated through a 100mm ball valve for rapid emptying. An additional 100mm ball valve provides direct suction access from the tank top, offering operational flexibility for different waste sources.

• Complete Suction Hose Kit: The truck comes standard with one 8-meter suction hose equipped with male and female quick couplings, ensuring compatibility with various waste disposal sites and allowing operators to reach confined spaces.

• Convenient Storage: Dual side toolboxes are integrated into the chassis design, providing secure storage for hoses, fittings, tools, and personal protective equipment, keeping the work area organized.

• Operational Safety: The rear is fitted with standard safety markings and lighting for road use during low-light conditions, and all controls are positioned for safe operation.

Chengli Group Manufacturer Advantages:

• Industry Leadership: As a leading manufacturer in the Hubei Suizhou special vehicle industry, Chengli (CLW) Group leverages massive economies of scale to offer competitive pricing without compromising on quality. The factory-direct sales model ensures customers receive the best value and direct support.

• Customization & Compliance: All vehicles come with full national certification, environmental protection compliance, and CCC certifications, ensuring smooth registration and legal operation. Extensive customization options are available, such as stainless steel tank upgrades, high-pressure washing systems, and specialized pump configurations.

• Comprehensive After-Sales Support: A robust nationwide service network with rapid response times is provided. The commitment includes thorough operator training, a comprehensive one-year warranty, and lifetime technical support, ensuring equipment remains in peak operating condition for years to come.
