Fodi Ditu EF3 5m³ Pure Electric Compactor Truck – CL5040ZYSBEVAHQ
I. Product Introduction
The CL5040ZYSBEVAHQ is a pure electric rear-load compactor truck built on the Fodi Ditu EF3 chassis. Designed for urban sanitation and municipal waste collection, this 5 m³ compactor truck combines zero-emission operation with efficient compaction and high maneuverability. Powered by a CATL lithium iron phosphate battery and a Suzhou Inovance drive motor, it delivers quiet, reliable performance ideal for residential and commercial collection routes.
II. Core Parameters
Parameter | Specification |
|---|---|
Model | CL5040ZYSBEVAHQ |
Chassis | Fodi Ditu EF3 (FD1041D66BEV) |
Wheelbase | 3100 mm |
Compactor Volume | 5 m³ (Approx. 6.5 yd³) |
Battery Type | Lithium Iron Phosphate (LFP) |
Battery Brand | CATL |
Battery Capacity | 63.75 kWh |
Drive Motor | Suzhou Inovance |
Rated / Peak Power | 50 kW / 105 kW (143 hp) |
Range | Approx. 200 km (124 miles) |
Rear Axle | 3T electric drive axle, Hande maintenance-free |
Tires | 185R15 vacuum tires (rear dual) |
Warranty | 8 years or 400,000 km |
III. Dimensions, Body Specs, Material & Design Philosophy
Overall Dimensions (L×W×H): Approx. 5550 × 1950 × 2350 mm (chassis dependent)
Compactor Body: 5 m³ sealed design with high-strength wear-resistant steel
Material: Corrosion-resistant steel for the compaction chamber and hopper; reinforced side panels for durability
Design Philosophy: The compact dimensions with a 3100 mm wheelbase enable excellent maneuverability in narrow urban streets. The sealed body prevents leakage and odor, while the integrated electric drive system ensures quiet, emission-free operation for residential collection routes.
IV. Structural Advantages (Powertrain, Axle, Chassis)
Battery: The CATL 63.75 kWh lithium iron phosphate battery offers high safety, long cycle life, and consistent performance across temperatures. Backed by an 8-year / 400,000 km warranty.
Drive Motor: The Suzhou Inovance motor delivers 105 kW peak power (143 hp) and instant torque for smooth acceleration and reliable compaction power, even on stop-and-go routes.
Rear Axle: The 3T Hande maintenance-free electric drive axle integrates the motor, axle, and differential into a compact unit, reducing maintenance costs and improving energy efficiency.
Chassis: The Fodi Ditu EF3 chassis features a smart cab with wide-arm mirrors, ABS, central locking, and electric air conditioning for operator comfort.
V. Product Features & CLW Group Advantages
Product Features:
Zero-emission operation: Ideal for urban sanitation with noise reduction and no tailpipe emissions.
High compaction efficiency: Sealed compactor body with hydraulic system designed for 5 m³ capacity — suitable for daily residential and commercial waste collection.
Extended range: 200 km (124 miles) per charge supports full-day routes without intermediate charging.
Low maintenance: Maintenance-free rear axle and electric driveline reduce downtime and service costs.
CLW Group Advantages:
Integrated manufacturing: As a leading specialized vehicle manufacturer, CLW Group ensures seamless integration between the electric chassis and the compactor body.
Quality assurance: Each unit undergoes leak testing, compaction cycle testing, and electrical system validation before delivery.
Custom engineering: Tailored configurations available for bin lifters, hopper size, and compaction ratio based on municipal requirements.
After-sales support: Nationwide service network with OEM parts support for both Fodi chassis and compactor components.
