Isuzu 4×2 Regenerative Air Sweeper | Industrial-Grade Dry Road Cleaning Truck

I. Product Overview

The Isuzu Regenerative Air Sweeper is a specialized industrial-grade dry sweeping vehicle designed for demanding environments such as oil fields, mining sites, and large industrial facilities. It utilizes advanced regenerative air technology to efficiently collect dust, sand, debris, and industrial particulates without water, making it ideal for arid regions, winter operations, and areas where water usage must be minimized. This sweeper vehicle offers a reliable, low-maintenance solution for maintaining cleanliness and safety in critical work zones.

II. Key Specifications

• Chassis Model: Isuzu QL1070A5HAY (4×2 configuration)

• Total Mass: 7200 Kg

• Curb Weight: 4880 Kg

• Rated Load Capacity: 2190 Kg

• Overall Dimensions (L×W×H): 6190 × 1990 × 2590 mm

• Wheelbase: 3360 mm

• Max. Speed: 110 Km/h

• Emission Standard: GB17691-2018 China VI (Stage 6)

III. Tank Structure & Design Philosophy

• Tank Configuration & Capacity: Features a dual-compartment design with a 2.5 m³ fresh water tank (for dust suppression or system cleaning) and a primary 5 m³ debris hopper for collected material. The hopper design facilitates efficient unloading.

• Construction & Materials: The body and hopper utilize high-strength steel with integrated side protection (520mm ground clearance). The rear bumper is constructed from Q235 steel, ensuring durability and compliance with safety regulations.

• Design Concept: Focuses on operator safety, ease of use, and adaptability to rough terrain. The centralized electro-hydraulic control system allows convenient operation from the cab. The vehicle body itself serves as side protection, and the chassis-mounted components use an integrated, stacked hydraulic design for reliability and simplified maintenance.

IV. Chassis & Power System Advantages

• Reliable Powertrain: Powered by the efficient and proven Isuzu 4KH1CN6HS diesel engine (3.0L, 96 kW, China VI), known for its fuel economy and durability in tough conditions.

• Robust Driveline: Built on a rugged Isuzu QL1070A5HAY chassis with an 8/6+5 leaf spring suspension and 7.00R16 14PR tires, providing excellent load-bearing capacity and stability on uneven site roads.

• Dedicated Sweeping System Power: Equipped with a reliable Jiangling auxiliary diesel engine that independently powers the sweeping system, ensuring consistent performance regardless of vehicle travel speed.

• Safety & Control: Features standard ABS from Asia-Pacific Mechanical, power steering, and air conditioning for operator comfort and safety.

V. Product Features & Manufacturer Strengths

Core Product Features:

1. Advanced Regenerative Air System: The heart of this industrial sweeper is a maintenance-free centrifugal fan that creates a closed-loop airstream. It lifts and conveys debris into the hopper while filtering and reusing the air, ensuring high collection efficiency and minimal dust escape.

2. Terrain-Adaptive Sweeping Head: The centrally-mounted, floating suction nozzle automatically adjusts to ground contours, maintaining optimal seal and pickup efficiency over uneven surfaces like those found in mines and oil fields.

3. Efficient & Resilient Hydraulics: The system employs an integrated stacked valve design for compactness and reliability. Key components include a diaphragm pump (electromagnetic) for water supply, robust hydraulic cylinders, and a maintenance-free automatic clutch for the fan drive. A manual emergency pump ensures functionality in case of auxiliary power loss.

4. Optimized for Industrial Use: With a maximum sweeping width of 2.8 meters and a dedicated design for dust collection in oil, gas, and mining sectors, this mining vehicle significantly improves worksite environmental conditions and safety.

Chengli Group Advantages:

1. Specialization in Custom Utility Vehicles: Chengli possesses extensive expertise in modifying Isuzu and other premium chassis for specialized applications, ensuring seamless integration between the reliable base vehicle and the custom sweeping body.

2. Focus on Durability & Low Maintenance: The design emphasizes components like the maintenance-free fan and clutch, and the robust hydraulic system, aiming to reduce total cost of ownership and maximize uptime in remote or continuous-use scenarios.

3. End-to-End Customer Support: From initial configuration based on specific site needs to comprehensive after-sales service, parts supply, and operator guidance, Chengli provides full lifecycle support for its specialized vehicles.

4. Proven Integration Quality: As a leading special vehicle manufacturer, Chengli's integration process meets high standards for welding, assembly, and system testing, resulting in a cohesive and reliable final product ready for harsh operational environments.

Contact us today to learn more about this durable and efficient dry sweeping solution for your industrial cleaning and mining site maintenance needs.
