Product Introduction: Sinotruk 6×4 Hook Arm Garbage Truck is optionally equipped with a 20-30 ton telescopic arm, paired with an 18-20 cubic meter compression garbage station

1. Product Overview

The Chengliwei CLW5250ZXXBHJ is a heavy-duty tri-axle hook lift transport vehicle designed for large-scale waste management operations and heavy material handling applications. Built on the robust Sinotruk 6×4 commercial truck platform, this detachable container transport system delivers exceptional load capacity performance and operational flexibility for municipal solid waste collection, industrial waste transportation logistics, and construction debris removal services. Engineered for demanding operating environments, it combines powerful performance characteristics with efficient container interchange capabilities to optimize waste logistics operations and material transport efficiency.

2. Core Specifications

• Product Model: Chengliwei CLW5250ZXXBHJ 6×4 Hook Lift Garbage Truck

• Environmental Compliance: China VI (Guoliu) Emission Standard certified heavy-duty diesel vehicle

• Gross Vehicle Weight Rating (GVWR): 25,000 kg

• Legal Payload Capacity: 14,095–14,160 kg range

• Kerb Weight: 10,710 kg

• Maximum Road Speed: 89 km/h

• Container System: Standardized detachable container compatibility

• Fuel System: Diesel-powered commercial transport vehicle

3. Dimensions, Body Construction & Engineering Design

• Overall Vehicle Dimensions (L×W×H): 8,330 mm length × 2,550 mm width × 3,190 mm height

• Chassis Frame Engineering: Features (7+4/280) double-layer reinforced heavy-duty frame construction for maximum structural integrity and heavy-load endurance performance

• Hook Arm System Construction: Manufactured from T710 premium high-strength alloy steel using precision welding technology, ensuring superior durability characteristics and long-term operational reliability in rigorous working conditions

• Design Philosophy: Focused on high payload efficiency optimization, stable container handling performance, and operator safety protocols, with optimized weight distribution engineering for enhanced road stability and transport safety

4. Chassis & Powertrain System Advantages

• Chassis Platform: Sinotruk ZZ1254N5747F11 6×4 heavy-duty tri-axle commercial truck chassis

• Engine Performance: Powered by Yuchai YCS06270-60 heavy-duty diesel engine (270 horsepower), delivering superior torque output, excellent fuel efficiency metrics, and reliable performance characteristics under maximum load conditions

• Transmission System: Equipped with HW11708STCL heavy-duty transmission (with overdrive capability) and flange-mounted power take-off (PTO) unit, providing smooth power transfer performance and versatile auxiliary power options for hydraulic system operation

• Axle & Suspension System: Robust front axle and tandem rear axle configuration with multi-stage parabolic leaf spring suspension (11/12, 11/10, 4/5, 8/10 variants) for exceptional load support capability and improved ride comfort on various road surfaces

• Tire & Wheel Configuration: 12R22.5 18PR or 11.00R20 18PR steel-belted radial commercial tires ensuring excellent road traction performance and maximum load-bearing capacity

• Operator Cabin Environment: Sinotruk V56X commercial cabin featuring air-suspension driver seating, multi-function ergonomic steering wheel, climate control air conditioning system, power window controls, central locking mechanism, ABS braking system, and maintenance-free battery system for premium driver comfort and operational convenience

5. Key Features & Manufacturer Capabilities

• Hydraulic System Technology: Utilizes WanYe high-pressure hydraulic gear pumps and large-diameter pneumatic control multi-directional valve blocks (with integrated safety valve protection) for reliable hydraulic performance and safe system operation

• Safety Engineering Features: Includes built-in bi-directional safety valves within hydraulic cylinders, reinforced hydraulic rear support systems, enhanced transverse container locking mechanisms, and optional hydraulic expansion interface connections for secure container handling procedures

• Control & Operation Systems: Offers dual-mode manual and remote control operation (wired control panel + wireless remote transmitter) for flexible container management and efficient operational control

• Container Compatibility System: Designed for standardized detachable container interfaces with quick-connect mechanisms for rapid container exchange operations and multi-point collection efficiency

• Chengli Specialized Vehicle Manufacturing Advantages: As a leading Chinese specialized vehicle manufacturer and exporter, Chengli provides comprehensive vehicle customization services, rigorous quality assurance testing protocols, nationwide after-sales service network, and competitive commercial vehicle pricing solutions. This model demonstrates their engineering expertise in developing high-capacity, durable transport equipment specifically engineered for municipal sanitation authorities, professional waste management companies, industrial facility operators, and construction project managers requiring heavy-duty material handling solutions and optimized logistics operations in demanding waste management systems and industrial transportation applications.
