Dongfeng Tianjin Five-Car Carrier – High-Capacity Car Transport Truck for Logistics & Recovery
I. Product Introduction
The Dongfeng Tianjin Five-Car Carrier is a high-capacity specialized transport vehicle designed for efficient vehicle logistics, new car delivery, and recovery operations. Built on a dedicated car carrier chassis with a semi-sleeper cab, this five-car carrier is available with multiple engine options including Cummins 6-cylinder 230HP, Cummins 4-cylinder 240HP, Yuchai 6-cylinder 220HP, and Yuchai 6-cylinder 245HP—all featuring engine cylinder brakes for enhanced safety. Equipped with a Fast 8-speed transmission, Dongfeng Dana axles (5T front / 10T rear), and a 250(7+4) high-strength frame, this car carrier truck delivers exceptional performance for automotive logistics, used vehicle transport, and accident recovery. As a product of Chengli Group—a leading specialized vehicle manufacturer—this carrier combines high loading capacity with superior build quality.
II. Core Specifications
Parameter | Specification |
|---|---|
Chassis | Dongfeng Tianjin car carrier chassis |
Cab | Semi-sleeper cab with sleeper berth |
Engine Options | Cummins 6-cyl 230HP / Cummins 4-cyl 240HP / Yuchai 6-cyl 220HP / Yuchai 6-cyl 245HP |
Engine Brake | Cylinder brake (standard) |
Transmission | Fast 8-speed manual |
Front Axle | 5-ton |
Rear Axle | 10-ton |
Frame | 250(7+4) high-strength frame |
Tires | 295/60R22.5 vacuum tires |
Air Conditioning | Original Pai'en A/C |
Fuel Tank | 250L aluminum alloy |
Security | Remote central locking, remote power windows |
III. Dimensions, Materials & Design Philosophy
Dimensions
Component | Length |
|---|---|
Upper Deck | 13–14m (0.5m front manual extension + 1.5m rear hydraulic extension) |
Lower Deck | 10m |
Upper Deck Height (from ground) | 2.7m |
Lower Deck Loading Height (from ground) | 0.7m (minimum) |
Deck Spacing | 0–2.4m (infinitely adjustable) |
Material
Upper Structure: Low-alloy high-strength steel
Paint: Automotive-grade (car-level) paint finish
Design Philosophy
Flexible Loading Capacity: Upper deck extends to 13–14 meters (with front manual and rear hydraulic extensions), lower deck measures 10 meters, accommodating up to five standard passenger vehicles.
Ultra-Low Loading Height: 0.7m lower deck height from ground for easy vehicle loading/unloading.
Adjustable Deck Spacing: Upper and lower deck spacing can be infinitely adjusted from 0 to 2.4 meters to accommodate various vehicle heights—sedans, SUVs, and MPVs.
Stability & Safety: Engine cylinder brake, high-strength frame, and robust axle configuration ensure stable and safe transport.
IV. Structural & Component Advantages
Engine Options – Multiple Power Choices
The Dongfeng car carrier offers four engine options to meet diverse operational needs:
Cummins 6-cylinder 230HP – proven reliability for standard transport operations
Cummins 4-cylinder 240HP – high power density for versatile applications
Yuchai 6-cylinder 220HP – fuel-efficient choice for long-haul logistics
Yuchai 6-cylinder 245HP – maximum power for heavy-duty operations
Engine Cylinder Brake: Standard equipment significantly enhances downhill braking safety and reduces brake wear, especially important for fully loaded car carriers.
Transmission – Fast 8-Speed
Provides smooth, reliable gear shifting with optimized gear ratios that complement the engine's torque curve, enhancing fuel efficiency and drivability across diverse road conditions.
Axles – Dongfeng Dana
The 5-ton front axle combined with the 10-ton rear axle delivers superior load-carrying capacity and stability. This robust axle configuration ensures durability when transporting up to five passenger vehicles.
Frame – 250(7+4) High-Strength
The high-strength frame structure significantly enhances torsional rigidity and bending resistance, providing a stable foundation for the car carrier body and ensuring long-term durability under high-load operations.
V. Hydraulic System – Imported High-Performance Components
The five-car carrier is equipped with a premium hydraulic system for smooth, precise deck operation.
Component | Specification |
|---|---|
Hydraulic Cylinders | 10 cylinders (imported oil seals) |
Synchronization | Fully synchronized operation |
Control System | Italian Hydra (海德) hydraulic control system |
10 Hydraulic Cylinders: Provides powerful and synchronized lifting for the upper deck.
Fully Synchronized: All cylinders operate in perfect unison, ensuring stable and level deck movement.
Italian Hydra Control: Precision hydraulic control system from Hydra (Italy) for reliable and responsive operation.
Imported Oil Seals: High-quality imported seals ensure leak-free operation and long service life.
VI. Product Features
Five-Car Capacity: Upper deck (13–14m) + lower deck (10m) accommodates up to five standard passenger vehicles.
Ultra-Low Loading Height: 0.7m lower deck height from ground facilitates easy loading/unloading without special ramps.
Infinitely Adjustable Deck Spacing: Upper and lower deck spacing adjustable from 0 to 2.4 meters—accommodates sedans, SUVs, and MPVs of varying heights.
Hydraulic Extensions: Rear hydraulic extension (1.5m) and front manual extension (0.5m) provide flexibility for different vehicle lengths.
High-Strength Steel Construction: Upper structure fabricated from low-alloy high-strength materials for durability without excessive weight.
Automotive-Grade Paint: Premium car-level paint finish for long-lasting appearance and corrosion protection.
24 Tie-Down Straps: Included for secure vehicle fastening during transport.
Comprehensive Tool Kit: Complete set of tools included with the vehicle.
Driver Comfort: Semi-sleeper cab with sleeper berth, original A/C, remote central locking, and remote power windows.
VII. Applications
The Dongfeng Tianjin five-car carrier is specifically designed for:
New Vehicle Logistics: Zero-kilometer delivery of new passenger vehicles from factories to dealerships.
Used Vehicle Transport: Efficient transport of multiple used vehicles between cities and regions.
Accident Recovery: Recovery and transport of damaged vehicles from accident scenes.
Airport & Port Logistics: Vehicle transport to and from airports and shipping ports.
Rental Fleet Relocation: Moving rental fleet vehicles between different locations.
Auction & Wholesale Transport: Transporting vehicles to and from auctions and wholesale markets.
VIII. Chengli Group Manufacturer Advantages
Chengli Group (CLW Special Purpose Vehicle Co., Ltd.) is a leading manufacturer of specialized vehicles in China, with a strong reputation in the car carrier truck segment.
Industry Leader: Chengli Group is recognized as a Top 500 Chinese Private Enterprise and holds designations from the China Ministry of Industry and Information Technology for specialized vehicle manufacturing.
Global Presence: Since 2004, Chengli (CLW) vehicles have been exported worldwide, building a reputation for quality and reliable after-sales service.
Integrated Manufacturing: As a core enterprise of Chengli Group, the company operates a complete production chain from chassis integration to body fabrication, ensuring quality control and cost efficiency.
Continuous Innovation: Chengli consistently updates its product line with advanced features like Italian Hydra hydraulic control systems and automotive-grade paint finishes.
Quality Assurance: Strict quality control at every stage, from material selection to final assembly.
After-Sales Support: Comprehensive after-sales service, including spare parts availability and technical support.
This Dongfeng Tianjin five-car carrier represents Chengli's commitment to delivering efficient, durable, and operator-friendly transport solutions for the modern logistics and automotive industries.
