JMC Green Comprehensive Maintenance Truck – Integrated Hedge Trimming & Collection Solution

I. Product Introduction

The JMC Green Comprehensive Maintenance Truck is a specialized vehicle designed for modern urban landscaping and highway green belt maintenance. As an Integrated Hedge Trimming & Collection Truck, it combines hedge trimming, debris collection, and optional watering functions into a single efficient platform. Whether serving as a Highway Green Belt Maintenance Truck for roadside vegetation management or a versatile Landscaping Maintenance Vehicle for municipal parks, this model delivers exceptional performance. Designed to function as a Hedge Trimmer with Debris Collection, it enables a single operator to complete trimming, crushing, and collection in one pass, significantly improving productivity while reducing labor costs and road safety hazards. As a dedicated Roadside Vegetation Management Truck, it addresses the limitations of manual trimming—including low efficiency, safety risks, and the need for secondary cleaning.

II. Core Parameters

• Model: CL5080TYH6YC / HYS5080TYHJ6

• Chassis Model: JX1083TG26

• Overall Dimensions (L×W×H): 5,980 mm × 2,160 mm × 3,190 mm

• Wheelbase: 3,360 mm — optimized for stability and maneuverability on highways and urban streets

• Engine: JMC diesel engine, 152 hp (112 kW), 2.892 L displacement, meeting National VI emission standards

• Transmission: 6-speed manual transmission (Getrag) with synchronized gear engagement

• Tire Specification: 7.50R16LT steel-belted radial tires, providing reliable load-carrying capacity

• Gross Vehicle Weight (GVWR): 4,495 kg – 6,580 kg depending on configuration

• Storage Tank Capacity: 3.5 m³ (approx. 124 cubic feet) for collected debris; optional 1.0 m³ (approx. 35 cubic feet) plastic water tank for spraying functions

• Trimming Speed: 1.2 – 6 km/h, adjustable for varying vegetation densities

• Maximum Trimming Diameter: ≥20 mm (approx. 0.8 in) branches

• Trimming Height Range: 100 mm – 4,500 mm (approx. 0.3 – 14.8 ft), covering ground cover to high-level branches

• Maximum Trimming Width: 1,350 mm (approx. 53 in) per pass

• Horizontal Reach: Maximum extension of 2,350 mm (approx. 92.5 in) from vehicle side

III. Exterior Dimensions, Cargo Box Specifications, Material, and Design Philosophy

• Chassis Type: JMC Kaiyun wide-body cab with air conditioning, power windows, central locking, and multi-function steering wheel

• Storage Tank Construction: High-strength carbon steel with hydraulic tailgate opening and hydraulic dumping for efficient unloading

• Collection System: Large-capacity centrifugal fan (maintenance-free) creates negative pressure to draw trimmed debris through polyurethane steel-wire reinforced suction hoses into the storage tank

• Tank Features: Rear visual inspection window allows operators to monitor fill levels; safety support rods protect maintenance personnel when tank is raised

• Design Philosophy: As a true Integrated Hedge Trimming & Collection Truck, this vehicle adopts an integrated trimming and collection design philosophy, eliminating the need for secondary manual cleaning. Its role as a Roadside Vegetation Management Truck is reflected in the compact overall dimensions that ensure excellent urban maneuverability, while the multi-degree-of-freedom robotic arm provides extensive operational reach for diverse landscaping scenarios—from roadside hedges to median strips and elevated branches. The system incorporates intelligent logic interlocks that prevent unsafe operations (e.g., tank cannot tilt when trimming arm is deployed).

IV. Structural Advantages: Engine, Transmission, Front and Rear Axle

• Main Engine & Powertrain: The JMC JX4D306H diesel engine produces 152 hp (112 kW), delivering ample power for both driving and powering the hydraulic system. The engine meets National VI emission standards, ensuring compliance for export markets.

• Transmission System: Equipped with a 6-speed manual transmission (Getrag) featuring synchronized gear engagement for smooth shifting and reduced driver fatigue during extended landscaping routes.

• Front Axle: 3.0-ton rated front axle with forged I-beam construction, providing precise steering control and durability.

• Rear Axle: 5.5-ton rated rear axle with leaf spring suspension (8/7+7 spring leaves), specifically configured to support the combined weight of the storage tank, collected debris, and hydraulic equipment.

• Braking System: Air brake system with spring-loaded parking brake, ensuring reliable stopping performance even under full load conditions.

• Auxiliary Engine: A secondary engine (Yunnei or equivalent) powers the hydraulic system and centrifugal fan, allowing trimming operations independent of the chassis engine for optimized fuel efficiency.

• Hydraulic System: The entire trimming mechanism is hydraulically driven, offering advantages including compact size, low inertia, fast response, and self-lubricating moving surfaces for extended service life. System operating pressure is maintained at ≤16 MPa.

V. Product Features and Chengli Group Manufacturer Advantages

• Robotic Trimming Arm: As a specialized Hedge Trimmer with Debris Collection, the vehicle features a multi-degree-of-freedom robotic arm with 360° rotation capability, enabling trimming on both left and right sides of the vehicle without repositioning. The arm can perform horizontal, vertical, and angled cuts, adapting to various hedge shapes including flat, trapezoidal, and tower profiles.

• One-Key Operation: The operator controls all trimming functions through an in-cab touchscreen interface, with features including one-key arm retraction and laser guidance to assist with maintaining a straight path during median strip trimming.

• Intelligent Control System: The system incorporates logic interlock to prevent accidental operation—for example, the storage tank cannot tilt when the trimming arm is deployed, ensuring operational safety.

• Dust Suppression: Small spray nozzles on both sides of the vehicle provide dust control during operation; additional nozzles at the suction inlet pre-wet debris before entry into the collection system.

• Multi-Function Capability: This Landscaping Maintenance Vehicle can be equipped with optional attachments including:

  • Front-mounted electric water cannon for irrigation and fire prevention

  • Highway guardrail cleaning system for median barrier maintenance

  • Rear impact attenuator for enhanced safety during highway operations

• All-Weather Operation: As a reliable Highway Green Belt Maintenance Truck, the system is designed to operate reliably in temperatures ranging from -20°C to 40°C (-4°F to 104°F), with components selected for durability under diverse climate conditions.

• Chengli Group Strengths: As a premier manufacturer of specialized vehicles in China, Chengli Group brings extensive experience in green maintenance equipment production to this export model. The company utilizes advanced manufacturing processes and rigorous quality control to ensure consistent performance and durability. With a global export presence spanning over 100 countries and regions, Chengli provides localized support through established distribution channels. Each vehicle is built to meet international standards for safety, environmental compliance, and operational reliability, making it a trusted Roadside Vegetation Management Truck for municipal landscaping departments, highway maintenance agencies, and commercial landscaping operations worldwide.

This JMC Green Comprehensive Maintenance Truck is fully assembled and tested, ready for deployment as a premium Integrated Hedge Trimming & Collection Truck, Highway Green Belt Maintenance Truck, Landscaping Maintenance Vehicle, Hedge Trimmer with Debris Collection, and Roadside Vegetation Management Truck for urban landscaping and highway maintenance fleets seeking an efficient, safe, and multi-functional solution for hedge trimming, debris collection, and green belt maintenance.
