Foton Light Duty Refrigerated Truck Frozen Food Mini Truck – Product Introduction

1. Product Introduction

The light duty refrigerated truck frozen food mini truck represents a reliable solution for urban cold chain logistics. This reefer truck combines a compact chassis with advanced insulation technology, making it ideal for last-mile delivery of frozen food, dairy products, and other temperature-sensitive cargo in congested city environments.

2. Key Specifications

3. Dimensions, Material & Design Concept

• Overall Dimensions (L×W×H): 4960×1720×2515 mm

• Cargo Box Dimensions (L×W×H): 2795×1545×1535 mm

• Insulation Thickness: 8cm XPS extruded polystyrene board

• Box Material: Inner and outer walls feature premium 2.0mm fiberglass reinforced plastic (FRP)—offering excellent light reflection, thermal insulation, hardness, and oxidation resistance. The floor is constructed with FRP patterned plate for durability and slip resistance.

• Manufacturing Process: The cargo box is produced using vacuum adsorption and hydraulic integrated molding technology, creating a sandwich composite bond that meets national Class A insulation standards.

• Design Concept: As a premium insulated van, this vehicle is engineered for urban efficiency, featuring a compact 3070mm wheelbase that delivers exceptional maneuverability in narrow city streets while maintaining robust thermal integrity for perishable goods transport.

4. Structural Advantages: Powertrain & Chassis

This light duty refrigerated truck frozen food mini truck is built on a robust chassis platform with multiple brand options to meet diverse operational requirements.

• Engine: Powered by a 1.6L high-configuration gasoline engine, this vehicle delivers responsive power output ideal for stop-and-go urban driving conditions. The powertrain is optimized for fuel efficiency and smooth operation, ensuring reliable performance throughout the delivery route.

• Transmission: The 5-speed manual transmission provides precise gear selection and excellent control, allowing drivers to optimize power delivery for varying road conditions and load weights.

• Front & Rear Axles: Equipped with a 1.5T rear axle and front stabilizer bar, the chassis delivers exceptional stability and load distribution. The electric power steering system ensures effortless maneuverability, reducing driver fatigue during frequent urban deliveries.

• Chassis Features: Additional chassis enhancements include ABS braking system, 175R14 tires, central locking, and electric air conditioning—providing both safety and driver comfort.

• Chassis Brand Options: Customers can choose from a wide range of trusted chassis brands to suit their specific needs, including Sinotruk, Beiben Trucks, Shacman, FAW Jiefang, Isuzu, Hongyan Heavy Trucks, Foton Heavy Trucks, Dongfeng Heavy Trucks, and JAC Heavy Trucks.

5. Product Features & Manufacturer Advantages (CLW Group)

This cold chain truck stands out due to its specialized features and the strong backing of a leading manufacturer.

• Superior Insulation Performance: The 8cm XPS extruded polystyrene insulation layer combined with the vacuum adsorption molding process ensures minimal thermal loss, maintaining consistent temperatures for frozen and chilled goods. The 15cm anti-collision plate inside the cargo area protects the walls from pallet and cargo impact during loading and unloading.

• Premium Construction Details: The cargo box features aluminum alloy edge trim, stainless steel corner guards, stainless steel door locks, hinges, and frames, as well as energy-efficient LED lighting inside the compartment. The sub-frame guard is treated with electrophoretic paint for enhanced corrosion resistance.

• Refrigeration Unit Options: The vehicle is compatible with a wide selection of leading refrigeration unit brands, including USA Carrier, Thermo King, Korea Han Ya, China Songhan, and Hanxue. The temperature range is adjustable from 0℃ to -20℃, providing flexibility for various frozen and chilled applications. All selected refrigeration units feature simple structure, easy operation, reliable performance, low energy consumption, high cooling capacity, low noise, and convenient installation and maintenance.

• Light-Duty Versatility: As a light duty refrigerated truck frozen food mini truck, this model is perfectly suited for urban delivery routes, offering the ideal balance of payload capacity, maneuverability, and fuel efficiency.

• Sealing & Durability: The labyrinth-style rubber door seal provides superior airtightness, preventing cold air leakage and maintaining temperature stability throughout the transport journey.

• Manufacturer Advantages (CLW Group): In recent years, CLW Group has significantly increased its investment in technology research, automation, and intelligent manufacturing. The company has introduced advanced production equipment including plasma laser cutting, robotic welding production lines, automatic plate shearing production lines, fully enclosed waste gas recovery paint booths, water-based paint automatic spraying equipment, and complete vehicle assembly lines. These investments have greatly enhanced product craftsmanship, providing solid guarantees for the quality, safety, stability, and reliability of special-purpose vehicles and emergency equipment. For inquiries regarding refrigerated truck price, customers can contact us directly to receive customized quotes based on specific configuration requirements. We also offer a comprehensive after-sales service system, including video technical support, on-site installation, commissioning and training, online support, and on-site repair services.

6. Why Choose This Light Duty Refrigerated Truck Frozen Food Mini Truck

• Reliable Foton reefer truck platform with proven performance

• Compact mini truck design ideal for urban last-mile delivery

• Class A insulation standards with 8cm XPS foam core

• Multiple refrigeration unit brands and temperature range options

• Wide selection of trusted chassis brands

• CLW Group's advanced automated production lines ensure product quality

• Comprehensive after-sales support from CLW Group
