ISUZU 100P Refrigerated Truck – Compact 4.1-Meter Cold Chain Carrier for Urban Delivery

I. Product Introduction

The ISUZU 100P Refrigerated Truck is a compact and reliable cold chain vehicle designed for urban and suburban frozen and chilled cargo transport. Built on the legendary ISUZU 100P chassis, this vehicle is powered by a 120 HP ISUZU 4KH1CN6LB engine, delivering exceptional reliability and fuel efficiency for last-mile logistics, fresh food distribution, pharmaceutical delivery, and dairy transport. Equipped with a 4.1-meter insulated cargo box, this refrigerated truck offers excellent maneuverability for narrow city streets while maintaining temperature stability for temperature-sensitive goods. Manufactured by Chengli Group, a leading special-purpose vehicle manufacturer in China, this model combines ISUZU's world-class chassis with Chengli's advanced refrigeration body technology.

II. Core Parameters

III. Exterior Dimensions, Box Specifications & Design Philosophy

• Overall Dimensions: 5,995 × 1,960 × 2,835 mm – compact footprint optimized for urban delivery routes, narrow streets, and underground parking garages. At just under 6 meters in length, this vehicle can easily navigate tight urban environments.

• Cargo Box Dimensions: 4,100 × 1,740 × 1,750 mm – approximately 12.5 cubic meters of insulated storage capacity, ideal for last-mile refrigerated distribution.

• Box Construction: The cargo body is manufactured using vacuum adsorption and hydraulic press integrated production line technology – a state-of-the-art process ensuring uniform panel bonding without bubbles or delamination.

• Panel Material: Inner and outer walls are constructed from high-quality fiberglass (non-light-absorbing, high insulation, hard, oxidation-resistant). The middle insulation layer is XPS extruded polystyrene or PUR polyurethane foam.

• Insulation Thickness: 80 mm (8 cm) – meets national Class A insulation standards.

• Floor Material: Aluminum checkered plate – durable, slip-resistant, and easy to clean.

• Sealing: Labyrinth-type rubber door seals ensure airtight integrity.

• Hardware: Aluminum alloy edge trim, stainless steel corners, stainless steel door locks, hinges, and door frames – all corrosion-resistant for long service life.

• Lighting: Energy-efficient LED interior lights provide illumination without generating excess heat.

• Design Philosophy: "Compact reliability + ISUZU durability + Chengli craftsmanship" – This refrigerated truck combines the legendary ISUZU 100P chassis with Chengli's high-quality insulated cargo box, making it ideal for urban cold chain operators requiring maneuverability, reliability, and temperature stability.

IV. Structural Advantages – Engine, Chassis, Transmission & Cargo Box

ISUZU Powertrain & Chassis

• Engine (ISUZU 4KH1CN6LB – 120 HP): Delivers 120 HP with strong low-end torque for stop-and-go urban delivery routes. The ISUZU 4KH1CN6LB engine is globally renowned for its durability, fuel efficiency, and low maintenance costs – making it the preferred choice for light-duty refrigerated trucks worldwide.

• Transmission (5-Speed Manual): Factory-matched 5-speed manual transmission provides smooth, precise shifting with gear ratios optimized for urban delivery applications.

• Wheelbase (3,360 mm): Provides excellent stability for the 4.1-meter cargo box while maintaining a tight turning radius for navigating narrow city streets, residential alleys, and loading docks.

• Brake System (Oil Brake + ABS): Oil brake system provides smooth, progressive braking for urban stop-and-go driving. ABS ensures stability and control under emergency braking conditions.

• Tires (7.00R16 8PR): Durable, puncture-resistant tires suitable for daily urban delivery routes, providing excellent load capacity and stability.

• Suspension & Steering: Power steering reduces driver fatigue during frequent maneuvering. The ISUZU 100P chassis is engineered for light-duty applications with exceptional ride comfort and handling.

Cab Comfort & Driver Features

• ISUZU 100P Cab: Compact, ergonomic cab design with excellent visibility for urban navigation.

• Comfort & Convenience: Air conditioning, power steering, central locking, and power windows are all standard equipment – reducing driver fatigue on multi-stop routes.

• Safety: ABS ensures stable braking under emergency conditions. The oil brake system provides smooth, controlled braking for urban driving conditions.

Cargo Box & Refrigeration Preparation

• Box Dimensions (4,100 × 1,740 × 1,750 mm): Approximately 12.5 m³ capacity – ideal for frozen food transport, pharmaceutical cold chain, seafood logistics, dairy delivery, and fresh produce distribution.

• Insulation: 80mm XPS/PUR foam core with fiberglass skins provides superior thermal insulation, maintaining stable interior temperatures for chilled and frozen cargo.

• Refrigeration Ready: The cargo box is prepped for installation of a premium refrigeration unit (domestic or imported brands available). Minimum temperature down to -18°C.

V. Product Features & Manufacturer Advantages

Product Features

• ISUZU 100P Legendary Reliability: The ISUZU 100P platform is globally trusted for durability, low maintenance costs, and high resale value – making it the benchmark for light-duty refrigerated trucks.

• 120 HP ISUZU 4KH1CN6LB Engine: Proven engine delivers reliable power with excellent fuel efficiency for daily urban delivery routes.

• Compact 4.1-Meter Cargo Box: Approximately 12.5 m³ capacity – ideal for last-mile refrigerated distribution in urban environments.

• 80mm High-Density Insulation: XPS/PUR foam core with fiberglass skins meets national Class A insulation standards, maintaining stable temperatures for chilled and frozen cargo.

• Vacuum-Bonded Construction: Advanced manufacturing technology ensures bubble-free, high-strength panel bonding – preventing delamination and ensuring long-term durability.

• Total Length Under 6 Meters: At 5,995 mm overall length, this vehicle can easily navigate narrow streets, underground parking garages, and tight loading docks.

• Driver Comfort Package: Air conditioning, power windows, central locking, power steering, and ABS reduce driver fatigue on multi-stop routes.

• Versatile Applications: Suitable for frozen food distribution, pharmaceutical cold chain, seafood logistics, dairy delivery, fresh produce transport, and catering supply.

Chengli Group Manufacturer Advantages

Chengli Group is a leading manufacturer of special-purpose vehicles in China, bringing decades of expertise to every refrigerated truck. As the manufacturer of the CLW5040XLCQL6 model, Chengli Group offers significant advantages:

• Integrated Production: From chassis modification to cargo box assembly and refrigeration system installation, all processes are managed in-house, ensuring strict quality control and consistent workmanship.

• Advanced Manufacturing Technology: Chengli utilizes vacuum adsorption and hydraulic press integrated production lines, ensuring bubble-free, high-strength panel bonding for superior insulation performance.

• Large-Scale Production: Modern facilities with high annual capacity (over 1,000 units per month) ensure short delivery lead times and stable supply for export markets.

• Complete Quality Control: Every refrigerated truck undergoes rigorous pre-delivery inspection, including insulation integrity testing, panel adhesion verification, and refrigeration system performance validation.

• Certification Compliance: All vehicles are certified under national standards (CCC, ISO9001) with full documentation for smooth registration and export.

• Global Export Experience: Chengli vehicles are exported to markets worldwide, supported by comprehensive after-sales documentation and parts availability.

• Customization Capability: Flexible manufacturing allows for tailored configurations, including refrigeration unit brand (Carrier, Thermo King, or domestic options), insulation thickness, and interior fittings.

• Refrigeration Integration Expertise: Chengli has extensive experience integrating refrigeration systems with ISUZU chassis, ensuring seamless compatibility, optimal temperature control, and reliable performance.

ISUZU & Chengli – A Powerful Partnership

The combination of ISUZU's world-class chassis engineering and Chengli's advanced refrigeration body technology creates a refrigerated truck that delivers the best of both worlds: legendary ISUZU reliability and Chengli's proven cold chain expertise. This partnership ensures:

• Seamless Compatibility: Factory-engineered integration between chassis and refrigeration body.

• Optimal Temperature Control: Precision-engineered insulation and refrigeration system matching.

• Long-Term Durability: High-quality materials and construction techniques that withstand daily urban delivery demands.

• Global Support: Backed by both ISUZU's worldwide service network and Chengli's export after-sales support.
