ISUZU GIGA 4×2 Refrigerated Truck – 7.6-Meter Cold Chain Carrier

I. Product Introduction

The Qingling ISUZU GIGA 4×2 Refrigerated Truck is a versatile cold chain vehicle designed for medium to large-scale frozen and chilled cargo transport. Built on the reliable ISUZU GIGA 4×2 chassis, this vehicle is powered by a 205 HP ISUZU 4HK1-TCG60 engine, delivering exceptional performance for regional and long-haul logistics. Equipped with a spacious 7.6-meter insulated cargo box, this 7.6-meter refrigerated truck is ideal for frozen food distribution, pharmaceutical cold chain, seafood logistics, dairy transport, and fresh produce delivery.

II. Core Parameters

III. Exterior Dimensions, Box Specifications & Design Philosophy

• Overall Dimensions: 10,000 × 2,600 × 3,980 mm – optimized for maximum cargo capacity while maintaining excellent maneuverability for urban and regional delivery routes.

• Cargo Box Dimensions: 7,600 × 2,440 × 2,500 mm – spacious insulated cargo area providing approximately 46.4 cubic meters of cold chain storage capacity, ideal for refrigerated box truck configuration.

• Box Construction: High-quality insulated panels with reinforced flooring to withstand heavy palletized loads and frequent forklift loading.

• Wheelbase: 5,550 mm – provides excellent stability for the 4×2 configuration while maintaining a tight turning radius for city driving.

• Axles: 6.3-ton front axle and 13-ton rear axle – heavy-duty construction ensures exceptional load-carrying capacity for fully loaded refrigerated transport.

• Design Philosophy: "Balanced efficiency + ISUZU reliability" – This ISUZU GIGA 4×2 refrigerated truck combines a proven ISUZU powertrain with a spacious cargo box, driver-focused features, and robust chassis engineering for reliable cold chain operations.

IV. Structural Advantages – Engine, Chassis, Transmission & Cargo Box

ISUZU Powertrain & Chassis

• ISUZU 4HK1-TCG60 Engine (205 HP): Delivers 205 HP with strong low-end torque for heavy loads, providing excellent fuel efficiency and proven reliability for daily refrigerated logistics operations.

• Engine Displacement (5.19 L): Optimal displacement for medium to heavy-duty applications, balancing power output with fuel economy for regional and long-haul routes.

• Drive Type (4×2): The 4×2 configuration offers excellent fuel efficiency and lower operating costs compared to multi-axle configurations, making it ideal for regional refrigerated distribution.

• Transmission (ISUZU MLD 6-Speed Manual): Factory-matched ISUZU MLD transmission provides smooth, precise shifting with gear ratios optimized for refrigerated cargo applications.

• Front Axle (6.3T) & Rear Axle (13T): Heavy-duty axles provide exceptional load-carrying capacity, with the 13-ton rear axle ensuring stability and durability under full refrigerated loads.

• Brake System (ABS + Spring Brake): ABS ensures stable braking under emergency conditions. Spring brake provides reliable parking brake function on inclines.

• Tires (295/80R22.5 16PR): Heavy-duty radial tires provide excellent load capacity, durability, and stability for refrigerated transport operations.

Cab Comfort & Driver Features

• New ISUZU GIGA Cab (4X Series): Modern cab design with excellent visibility and ergonomic layout for reduced driver fatigue.

• Comfort & Convenience: Air conditioning, power steering, central locking with remote key, power windows, and multi-function steering wheel are all standard equipment.

• Electronics: Multi-function LCD instrument panel provides clear, easy-to-read vehicle data at a glance.

• Safety: ABS and spring brake ensure safe operation under all load conditions.

Cargo Box & Refrigeration Preparation

• Box Dimensions (7,600 × 2,440 × 2,500 mm): Spacious interior efficiently accommodates standard pallets – ideal for frozen food transport, pharmaceutical cold chain, seafood logistics, and fresh produce delivery.

• Insulation: High-density polyurethane foam insulation ensures temperature stability, making this vehicle suitable for both chilled and frozen cargo applications.

• Refrigeration Ready: The cargo box is prepped for installation of a premium refrigeration unit (Carrier or Thermo King recommended).

V. Product Features & Manufacturer Advantages

Product Features

• ISUZU 4×2 Reliability: The ISUZU GIGA platform is globally trusted for durability, low maintenance costs, and high resale value.

• 205 HP ISUZU Engine: Proven ISUZU 4HK1-TCG60 engine delivers reliable power with excellent fuel efficiency for daily refrigerated logistics operations.

• Heavy-Duty Axles (6.3T Front / 13T Rear): Robust construction provides exceptional load-carrying capacity for fully loaded refrigerated transport.

• 7.6-Meter Cargo Box: Approximately 46.4 m³ capacity – ideal for palletized frozen foods, fresh produce, dairy, pharmaceutical cold chain, and seafood logistics.

• Factory-Matched ISUZU MLD Transmission: Smooth, precise shifting with gear ratios optimized for refrigerated cargo applications.

• Driver Comfort Package: Air conditioning, power windows, central locking with remote key, and multi-function steering wheel reduce driver fatigue on long routes.

• Multi-Function LCD Instrument Panel: Clear, easy-to-read vehicle data at a glance for improved situational awareness.

• Versatile Applications: Suitable for frozen food transport, pharmaceutical cold chain, seafood logistics, dairy transport, and fresh produce delivery.

Manufacturer Advantages

Qingling ISUZU (manufactured in China) combines ISUZU's global engineering excellence with local manufacturing expertise, establishing itself as a professional refrigerated truck manufacturer. Key advantages include:

• ISUZU Original Technology: Factory-integrated chassis, cab, and powertrain based on authentic ISUZU engineering, ensuring seamless compatibility and optimal performance for every cold chain carrier.

• Proven Cold Chain Platform: The ISUZU GIGA chassis is a globally recognized platform for refrigerated box truck conversions, with years of proven reliability in cold chain logistics.

• Driver-Centric Design: Multi-function steering wheel, multi-function LCD instrument panel, and power amenities are standard – not optional.

• Heavy-Duty Chassis: 6.3-ton front axle and 13-ton rear axle provide exceptional load capacity for demanding refrigerated logistics operations.

• Global Service Network: Supported by ISUZU's worldwide after-sales network for parts and service availability.
