Foton Ollin Swift Refrigerated Truck – Professional Product Introduction | Foton 4x2 Refrigerated Truck with 4.2m box length and 18m³ cargo volume

I. Product Overview

The Foton Ollin Swift Refrigerated Truck is a medium-duty temperature-controlled delivery vehicle jointly developed by Foton, Daimler-Benz, and Cummins, representing the pinnacle of cold chain logistics engineering. This insulated transport truck is specifically designed for efficient urban and regional distribution of fresh food, frozen products, pharmaceuticals, and other temperature-sensitive goods. As a premium offering in the light-duty truck segment, this refrigerated freight solution combines a powerful Cummins engine with a spacious, ergonomic cab to deliver exceptional performance, fuel efficiency, and driver comfort for demanding cold chain operations. Manufactured by Chengli Group, a trusted refrigerated truck manufacturer, this vehicle represents the ideal choice for businesses seeking reliable temperature-controlled transportation.

II. Core Specifications

• Chassis Model: Foton Ollin Swift BJ5045XLC8JDA-AB1 truck chassis

• Engine Model: Foton Cummins F2.8NS6B131 diesel engine

• Power Output: 96 kW (131 Horsepower) engine power

• Displacement: 2780 ml (2.78L) engine displacement

• Emission Compliance: National Phase VI (Guo VI) emission standard

• Transmission: Manual gearbox / manual transmission

• Tires: 7.00R16LT radial tires / steel-belted tires

• Rear Axle: 5-Ton rear axle capacity

• Wheelbase: 3360 mm wheelbase

• Braking System: ABS anti-lock braking system

• Cab Features: 1880 mm wide-body metal paint cab (tilting design), EBP fuel-saving switch, front wide-angle mirror, power steering, multifunction steering wheel, frameless wipers, air conditioning, cruise control, central door lock, power windows, remote key entry, self-adjusting brake arms

III. Exterior Dimensions, Box Size, Materials & Design Philosophy

• Overall Vehicle Dimensions: 5995 x 2320 x 3265 mm exterior dimensions

• Insulated Cargo Box Internal Dimensions: 4085 x 2100 x 2100 mm (Approx. 18.0 cubic meters cargo capacity / 18.0 m³ load volume / 635 cubic feet / 18立方冷藏箱)

• Wheelbase: 3360 mm

• Box Construction Materials: The refrigerated compartment features a high-strength sandwich panel construction. The inner and outer walls are made of corrosion-resistant, high-strength fiberglass reinforced plastic (FRP) , providing excellent thermal insulation and oxidation resistance. The core insulation layer is composed of high-density polyurethane foam and XPS insulation board, ensuring minimal temperature fluctuation and superior thermal performance. Flooring features durable anti-slip aluminum tread plate for safe loading and unloading operations.

• Design Philosophy: The design prioritizes "Premium Performance with Superior Efficiency." Developed through the Foton-Daimler-Cummins alliance, this vehicle combines global engineering expertise with practical logistics requirements. The spacious 18.0 m³ cargo compartment is optimized for high-volume cold storage distribution, while the 1880 mm wide-body cab ensures driver comfort during extended routes. The focus is on creating a durable, thermally efficient mobile refrigeration unit that maximizes payload capacity while delivering exceptional fuel economy and driver satisfaction.

IV. Structural Advantages – Engine, Transmission, Axles & More

• Engine Performance & Reliability: The Foton Ollin Swift is powered by the Foton Cummins F2.8NS6B131 heavy-duty diesel engine, delivering 131 horsepower and 96 kW of power. This fuel-efficient engine features Cummins' exclusive EBP (Economy-Balance-Power) fuel-saving switch, allowing drivers to optimize fuel consumption based on load and road conditions. The engine is renowned for its durability, strong low-end torque, and reliable performance under load, making it ideal for refrigerated cargo transport applications requiring consistent temperature maintenance. The Cummins powertrain ensures long service life and reduced operating costs.

• Transmission & Drivetrain: Equipped with a manual transmission system, the drivetrain is engineered for smooth gear changes and optimal power delivery across various terrains, enhancing driver control and fuel economy during both highway cruising and urban delivery. The gearbox is perfectly matched to the engine's power curve for efficient operation in stop-and-go traffic.

• Chassis & Suspension: Built on a robust truck frame developed through the Foton-Daimler collaboration, the vehicle offers excellent stability and load-bearing capacity. The suspension system is tuned to absorb road vibrations, protecting sensitive cargo while ensuring durability under full load conditions.

• Front and Rear Axles: The 5-ton rear axle is specifically designed to handle the demanding payload of refrigerated freight, providing long-term durability and reliable performance under full load conditions. The front axle is engineered for precise steering and stability. Self-adjusting brake arms ensure consistent braking performance and reduced maintenance requirements.

• Advanced Safety & Driver Assistance Features: The vehicle is equipped with a comprehensive safety system, including ABS for stable braking, power steering for effortless handling, and a front wide-angle mirror for enhanced visibility. The frameless wipers provide superior windshield coverage in adverse weather conditions, improving driving safety.

• Cab Design & Driver Comfort: The 1880 mm wide-body metal paint cab features a tilting mechanism for easy engine access and maintenance access. The multifunction steering wheel integrates key controls for reduced driver distraction. Standard equipment includes air conditioning, cruise control, power windows, central door lock, and remote key, creating a driver-friendly environment that significantly reduces driver fatigue during long-haul operations.

V. Product Features & Chengli Group Manufacturer Advantages

• Superior Insulation Technology for Cold Storage: The refrigerated box body is manufactured using advanced vacuum adsorption and hydraulic adsorption one-piece molding production lines. This creates a seamless, high-density thermal barrier that guarantees temperature retention and significantly reduces the workload on the refrigeration unit, ensuring optimal energy savings and cooling performance. The high-density insulation maintains consistent interior temperatures even in extreme ambient conditions, providing reliable cold chain integrity and temperature stability for valuable cargo.

• Premium Global Collaboration Engineering: The Foton Ollin Swift represents the best of global automotive engineering, developed through the strategic alliance between Foton, Daimler-Benz, and Cummins. This collaboration ensures world-class commercial vehicle quality, reliability, and performance standards. The Foton-Daimler partnership brings German engineering excellence to the medium-duty truck segment.

• Fuel Efficiency & Operating Economy: The Cummins engine with EBP fuel-saving switch allows drivers to select the optimal power mode for their load and route, significantly reducing operating costs and fuel consumption without compromising performance. This fuel-saving technology can reduce total cost of ownership over the vehicle's lifetime.

• Driver-Focused Design for Long Hauls: The 1880 mm wide-body cab provides exceptional interior space and comfort. The tilting cab design facilitates easy maintenance access, reducing vehicle downtime and service costs. Standard convenience features including cruise control, air conditioning, and power accessories ensure driver satisfaction and productivity, making this a true driver-comfort truck.

• Durability & Low Maintenance: Self-adjusting brake arms, durable axle construction, and high-quality components throughout reduce maintenance costs and extend vehicle service life. The metal paint finish provides long-lasting corrosion protection and aesthetic appeal, maintaining resale value.

• Chengli Group Advantage – Specialized Vehicle Manufacturing Expertise: As a product of Chengli Group, a leader in the special purpose vehicle industry and a renowned commercial vehicle manufacturer, this medium-duty refrigerated truck benefits from decades of specialized manufacturing expertise. Our advantage lies in the precision engineering of the insulated compartment to perfectly match the chassis specifications. We seamlessly integrate the refrigeration system with the vehicle's electrical and mechanical architecture for reliable, worry-free operation. As a trusted refrigerated truck builder, we offer a complete, ready-to-deploy solution for temperature-sensitive logistics, food transportation, pharmaceutical distribution, frozen food delivery, grocery supply chain, and other cold supply chain needs globally. Our custom refrigerated solutions ensure that every vehicle meets the specific requirements of our customers' operations.
